Cable Glands
Double Compression E1XF Type Weatherproof, Waterproof Flameproof & Increased Safety Cable Glands for
Steel Wire Braided Cables (Gas Group I, IIA, IIB IIC)
Application
Suitable for all types of unarmoured plastic or rubber sheathed cables in indoor as well as outdoor installations.
It is used in applications where it is essential to provide an IP66/IP67 and explosion proof seal on the inner and
outer sheath of the cable. It is particularly suitable for Zone1 & Zone2 in hazardous area.
Features
The gland provides mechanical cable retention & electrical wire continuity via armour wire termination. If
provides an integral clamp for armoured cables. This armour clamp provides an electrical bond between the
cable armour and the gland.
Fire and Ingress Protection
II2 GD / Exd IIC / Exe II / Ext D A21 / IP66 / IP67, Allowable temperature on the elastomeric sealing ring:
100℃(ATEX), 120℃(GOST R)
Permitted Zone and Gas Group
Suitable for use in Zone1, Zone2, and Gas Groups, IIA, IIB and IIC
Certificate
IECEX KOSHA (IECEX KOS 09.0016x), ATEX NEMKO (02ATEX 501X), GOSTR
Material
Brass / Stainless Steel
Plating Option
Brass Finish, Nickel Finish, Chrome Finish or as specified
Accessories
Lock Nut, Sealing Washer, Earth Tag, Shroud, Lead Sheath Washer, Serrated Washer, Stopping Plug, Reducer,
Adaptor
Ordering Code
(Gland Type / Size & Entry Thread Size), e.g. E1XF 32a/M32 - 18mm
Technical Data
| Part No. |
Entry Thread Size |
Cable Diameter |
Thread Length. |
Entry Hole Size |
Braid Size |
Hexagon Dimensions (H) |
Weight |
Length |
| Metric |
NPT |
Inner "A" |
Outer "B" |
Metric |
NPT |
Metric |
NPT |
| E1XF-16a |
M16/M20 |
1/2" |
5 -11 |
8-13 |
15 |
15 |
17 |
22 |
0.05/0.8 |
H25X27 |
150 |
67 |
| E1XF-16b |
M16/M20 |
1/2" |
5 -11 |
12-15.1 |
15 |
15 |
17 |
22 |
0.05/0.8 |
H25X27 |
150 |
67 |
| E1XF-20a |
M20 |
1/2" or 3/4 |
8 -15.1 |
13-17.5 |
15 |
15or16 |
21 |
22 |
0.05/0.8 |
H31X33 |
235 |
74 |
| E1XF-20b |
M20 |
1/2" or 3/4 |
8 -15.1 |
16-19.5 |
15 |
15or16 |
21 |
22 |
0.05/0.8 |
H31X33 |
235 |
74 |
| E1XF-25a |
M25 |
3/4" or 1" |
13 -19.5 |
17.5-22 |
15 |
16or18 |
26 |
26 |
0.05/0.8 |
H36X39 |
290 |
79 |
| E1XF-25b |
M25 |
3/4" or 1" |
13 -19.5 |
21-26 |
15 |
16or18 |
26 |
26 |
0.05/0.8 |
H36X39 |
290 |
79 |
| E1XF-32a |
M32 |
1" or 1-1/4" |
17.5-26 |
22-28 |
15 |
18or19 |
33 |
34 |
0.05/1.2 |
H45X49 |
490 |
86 |
| E1XF-32b |
M32 |
1" or 1-1/4" |
17.5-26 |
27-32 |
15 |
18or19 |
33 |
34 |
0.05/1.2 |
H45X49 |
490 |
86 |
| E1XF-40a |
M40 |
1-1/4"or 1-1/2" |
22-32 |
30-35 |
15 |
19or21 |
41 |
43 |
0.05/1.2 |
H55X59 |
850 |
94 |
| E1XF-40b |
M40 |
1-1/4"or1-1/2" |
22-32 |
35.1-40 |
15 |
19or21 |
41 |
43 |
0.05/1.2 |
H55X59 |
850 |
94 |
| E1XF-50a |
M50 |
1-1/2" or2" |
30-41.5 |
38-45 |
15 |
21or24 |
51 |
50 |
0.05/1.2 |
H68X73 |
1390 |
100 |
| E1XF-50b |
M50 |
1-1/2" or2" |
30 -41.5 |
43-50 |
15 |
21or24 |
51 |
50 |
0.05/1.2 |
H68X73 |
1390 |
100 |
| E1XF-63a |
M63 |
2"or2-1/2" |
38-54 |
48-53 |
15 |
24or27 |
64 |
62 |
0.05/1.2 |
H82X88 |
2070 |
108 |
| E1XF-63b |
M63 |
2"or2-1/2" |
38-54 |
51 -56 |
15 |
24or27 |
64 |
62 |
0.05/1.2 |
H82X88 |
2070 |
108 |
| E1XF-63c |
M63 |
2" or2-1/2" |
38-54 |
55-60 |
15 |
24or27 |
64 |
62 |
0.05/1.2 |
H82X88 |
3270 |
108 |
| E1XF-75a |
M75 |
2-1/2"or 3" |
49-66 |
56-62 |
20 |
27or30 |
76 |
74 |
0.05/1.2 |
H98X106 |
3270 |
125 |
| E1XF-75b |
M75 |
2-1/2"or 3" |
49-66 |
62.1-66 |
20 |
27or30 |
76 |
74 |
0.05/1.2 |
H98X106 |
3270 |
125 |
| E1XF-75c |
M75 |
2-1/2"or 3" |
49-66 |
66.1-70 |
20 |
27or30 |
76 |
74 |
0.05/1.2 |
H98X106 |
3270 |
125 |
| E1XF-75d |
M75 |
2-1/2"or 3" |
49-66 |
68-75 |
20 |
27or30 |
76 |
74 |
0.05/1.2 |
H98X106 |
3270 |
125 |
| E1XF-90a |
M90 |
3" or3-1/2" |
63-77 |
74-83 |
20 |
30or32 |
91 |
90 |
0.05/1.6 |
H110X120 |
4600 |
132 |
| E1XF-90b |
M90 |
3" or3-1/2" |
63-77 |
82-90 |
20 |
30or32 |
91 |
90 |
0.05/1.6 |
H110X120 |
4600 |
132 |
| E1XF-100a |
M100 |
3-1/2 or4" |
73.1-85 |
89-94 |
20 |
32 |
101 |
102 |
0.05/1.6 |
H120X130 |
5500 |
144 |
| E1XF-100b |
M100 |
3-1/2 or4" |
73.1-85 |
93-98 |
20 |
32 |
101 |
102 |
0.05/1.6 |
H120X130 |
5500 |
144 |
